Systems

Kawneer’s 190, 350, and 500 entrance doors provide a range of stile widths to meet architectural, traffic, and hardware requirements across commercial, retail, and institutional projects. All models are constructed from high-strength aluminum extrusions and are fully compatible with Kawneer storefront and curtain wall framing systems.

Performance & Features

– Accommodates pivots or butt hinges, surface closers, concealed overhead closers
– Standard hardware options include maximum-security locks, touch bar panics, thresholds, and push/pull sets
– Infills range from 1/4″ to 1″ (6.4mm to 25.4mm)
– Custom mid-rails and bottom rails available for increased durability or hardware integration
– Finish options include clear and bronze anodized, plus custom painted finishes
– Fully integrated with Kawneer framing systems including 451T, Trifab®, and curtain wall series

Model Overview

– 190 Narrow Stile:
Designed for moderate traffic applications such as retail storefronts and offices
Slim vertical stile (2-1/8″), top rail (2-1/4″), bottom rail (3-7/8″)
Delivers a clean, minimal appearance while meeting standard performance needs

– 350 Medium Stile:
Ideal for schools, hospitals, and high-traffic commercial buildings
3-1/2″ stiles and top rail; bottom rail measures 6-1/2″ for added strength
Balances durability with a clean, proportional aesthetic

– 500 Wide Stile:
Suited for public buildings, banks, and government projects requiring a bold appearance
5″ stiles and top rail; 6-1/2″ bottom rail standard
Provides maximum strength and hardware flexibility for demanding environments
